International 1486 cumpărați folosit (8.939)

Condiție: necesită reparații (utilizat), Anul fabricației: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: 2460039, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL filtering system max 80 Bar : Knoll VRF450-2450 (!!! Can serve 2 machines at once) Fodpfxjxxrnbj Ag Aeft # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : NOT WORKING # Sensors for spindle tool presence & part presence # Tool breack sensors # Tool magasine piston and slide sistem door open/close 2 units # Tool magasine pistons and slide sistem tool holding sistem - 2 units # Position Encoder A axis # Inductive and magnetic sensors 4 units each # Chip extraction conveyor to be repaired # Chiller for cooling spindle/heat exchanger # Communication module Murr # Liniar scale X axis # Level sensor emulsion chip conveyor # Hydraulic pump # Motor for hydraulic pump (can be repaired) # Heat exchanger unit # Electric Siemens Contactors for electrical cabinet 3 units # Safety door lock Euchner # Emulsion filtration unit is shared with another machine (SW BA321 2460038)

Condiție: foarte bun (second hand), 771 UNITATE FOLOSITĂ Cameră de răcire și dospire WP pentru aprox. 20 de cărucioare 58x78. Echipament funcțional, după revizie. DIMENSIUNI EXTERIOARE (în cm): - lățime: 378 - lungime: 390 - înălțime: 286 + 45 (instalație electrică) DIMENSIUNI INTERIOARE (în cm): - lățime: 340 Ffedpfx Aotbwfpeg Aet - lungime: 350 - înălțime: 199 Echipamentul este pregătit pentru vizionare și se află în depozitul nostru (36-068 Bachórz, Polonia). Opțiuni suplimentare contra cost: renovare / transport / montaj / punere în funcțiune. Prețul indicat este preț net. VORBIM ENGLEZĂ, GERMANĂ, FRANCEZĂ, RUSĂ, UCRAINEANĂ.

Condiție: bun (utilizat), Funcționalitate: complet funcțional, diametrul lamei de ferăstrău: 350 mm, înălțime de tăiere (max.): 90 mm, lățime de tăiere (max.): 170 mm, Dotări: apărătoare pentru disc de ferăstrău, Fierăstrău circular de format mare pentru tăieri la unghi OMGA T50.350 2,2 kW Specificație: • Producător - OMGA • Model - T50.350 Fodpjx S Nt Djfx Ag Asft • Diametru disc - 350 mm • Motor fierăstrău - 2,2 kW • Dimensiuni maxime ale piesei tăiate la unghi drept: 90 x 170 mm (înalțime x lățime) • Protecții pe lamă pentru siguranța operatorului • Sistem propriu, intern de aspirare a rumegușului • Reglare tăiere +/- 45 de grade • Dimensiuni fără mese: 650 x 70 x 160 cm (L x l x î) • 2 mese extensibile de 17x100 cm incluse Informații suplimentare: • Mașina este în stare tehnică bună, gata de utilizare imediată • Fotografiile prezentate reflectă starea reală a obiectului oferit • Posibilitate de pornire și testare a echipamentului la fața locului

Condiție: bun (utilizat), Anul fabricației: 1990, În stare tehnică bună, complet funcțională. Ffsdpfxex Sqtfo Ag Aot An fabricație: 1990. Forța nominală a presei: 63 tone. Dimensiunile suprafeței de lucru a mesei: 800 x 630 mm. Greutatea utilajului: aprox. 6 tone.

Condiție: foarte bun (second hand), Mandrină profesională pentru burghiu cu con SK40 / ISO40 conform standardului DIN 69871 A. Producător: EROGLU Präzisionswerkzeuge (Germania) – precizie ridicată a execuției. Model: 03180PB05553 (3/16-IK). Cuplu maxim de strângere: 20 Nm – ideal pentru găurire și filetare cu forță controlată. Versiune cu răcire internă (IK – Innenkühlung). Mandrină cu reglarea cuplului + / –, ce permite protecția sculelor și a pieselor prelucrate. Construcție industrială solidă și durabilă – pentru utilizare pe centre de prelucrare CNC și mașini convenționale. Stare: folosită, în stare tehnică foarte bună – gata pentru utilizare imediată. ✅ Calitate germană – mandrină de precizie clasa industrială ✅ Ideală pentru producție și ateliere. Ffjdpsxlcz Sofx Ag Aot

Condiție: necesită reparații (utilizat), Anul fabricației: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: 2460038, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) Fodpfx Ajxxrc Sog Asft # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT (spindle) Machine status : NOT WORKING # Sensors for spindle tool presence & part presence # Hydraulic pump # Level & temperature sensor Parker for hydraulic unit # Tool magasine piston and slide system door open/close 2 units # Communication module Murr # Position encoder A Axis # Hydraulic switch Parker 4 units # Emulsion filtration unit is shared with another machine (SW BA321 2460038) # High pressure pump from emulsion filtration system

Condiție: bun (utilizat), 734 MALAXOR DE ALUAT tip brate, folosit, cu o capacitate de 300 l. Mașină în stare de funcționare, cu două viteze. DATE TEHNICE: - cuvă din oțel inoxidabil - braț de frământare tip brate, din oțel Ffsdpfjruad Nex Ag Aot DIMENSIUNI EXTERIOARE (cm): - lățime: 110 - adâncime: 124 - înălțime: 140 DIMENSIUNI INTERIOARE CUVA (cm): - diametru: 90 - înălțime: 49 Echipamentul este disponibil pentru vizionare în depozitul nostru (36-068 Bachórz, Polonia). Opțiuni contra cost disponibile: transport / montaj / punere în funcțiune a echipamentului. Prețul afișat este net. VORBIM ENGLEZĂ, GERMANĂ, FRANCEZĂ, RUSĂ, UCRAINEANĂ.

Condiție: nou, De vânzare: ansamblu industrial complet utilizat la lucrări de sudură robotizată marca CLOOS – producător german renumit de sisteme de automatizare. Setul conține: Arbore tubular (Hohlwelle kurz für W) • Marcaje: SA-Nr 455799, nr. piesă • Execuție robustă, din oțel • Fabricație: 25.05.2018 • Stare tehnică foarte bună, depozitat, urme minore de coroziune superficială Suport mare / adaptor de montaj (vizibile locașurile de fixare) Fedpfx Agow Rdyzj Asft • Construcție grea, solidă • Compatibil cu arborele pentru poziționare/rotație a componentelor de lucru • Fără jocuri, totul fix • Prindere codificată și trecere interioară Set ideal pentru: • Poziționere de sudare • Brațe de roboți industriali • Adaptarea acționărilor și reductoarelor

Condiție: necesită reparații (utilizat), Anul fabricației: 2012, Funcționalitate: nefuncțional, număr mașină/vehicul: 2560001, Technical characteristics: # Machining Workspace: X 600 mm; Y 525(890) mm; Z 400 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation C with index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 600 x 1420 mm; weight max 600 Kg # Rapid speed : X/Y/Z 50/60/50 m/min , Position precision Tp : 0.02 mm # Distance between spindles: 600 mm # Spindle speed 1-6000 rpm # Spindle nose: DIN69893-HSK-A100 (with internal refrigeration) # Automatic tool changer 2x20 tools / chip to chip medium 4.25 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space W x H x L : aprox. 5.8 x 3.3x 5.05 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll KF200/1200 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM # Control tool breakage length checker: Blum Novotec # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : NOT WORKING # Automatic doors operator access Ffedpfxoxxkd Uo Ag Aot # Tool magazine # Work place Axis protections # Z axis ballscrew and # Z axis Sliding patinas # hydraulic overheating # Hydraulic pump (250 bar)

Condiție: bun (utilizat), 744 UTILIZAT Cuptor cu punți, încărcare manuală, Matador MD 101 cu suprafață de coacere de 12 mp. DIMENSIUNI INTERIOARE ALE CAMEREI DE COACERE (în cm): - lățime 120 - adâncime 200 - înălțime: 3 rafturi superioare 20, 2 rafturi inferioare (extensibile) 14 Fsdpfsrvxtzsx Ag Aeft DIMENSIUNI EXTERIOARE ALE CUPTORULUI (în cm): - lățime 183 - adâncime 340 - înălțime 235 ECHIPARE: - arzător pe gaz sau pe ulei Echipamentul este pregătit pentru inspecție în depozitul nostru (36-068 Bachórz, Polonia). Opțiuni suplimentare contra cost: recondiționare / transport / montaj / punere în funcțiune. Prețul menționat este preț net. VORBIM ENGLEZĂ, GERMANĂ, FRANCEZĂ, RUSĂ, UCRAINEANĂ.

Condiție: foarte bun (second hand), Vând dispozitiv profesional pentru setarea alezometrelor SUBITO – Schwenk ESU. Stare foarte bună, set complet în cutia originală de lemn, cu instrucțiuni. • Model: SUBITO Einstellgerät ESU • Producător: Oskar Schwenk GmbH, Germania • Echipament complet • Bază stabilă din fontă • Reglare precisă cu avans micrometric • Ideal pentru setarea alezometrelor SUBITO, ESS, ESU • Totul în stare ca nouă. Fodpfox A Ia Iox Ag Ajft

Condiție: necesită reparații (utilizat), Anul fabricației: 2009, Funcționalitate: nefuncțional, număr mașină/vehicul: B-8024, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor:850 mm (max load 450 Kg) # Nº of T.Slots:3/Distance between T.Slots: 125mm /Width of T.Slots: 18mm # Axis description: 3 LINIAR AXIS(X,Y,Z) +2 twin horizontal spindles + 4 th Axis # Rapid speed : X,Y,Z - 30m/min # Work travel : Longitudinal travel (x-axis) 600 mm,Cross Travel (y-axis) 400 mm,Vertical Travel (z-axis) 510 mm Headstock capabilities: # Spindles distance : 200 mm # Max. distance from spindle to table 650 mm # Spindle nose: ISO7388 (with internal refrigeration),Tool Holder (Size 40) # Speed range (standard)100/8000,Maximum torque / at 330 rpm,85 Nm ,7.5 kw Automatic tool changer: # Number of tools :20 ,Selection system:Sequential-/random,Max. diameter (adjacent tool)85 mm, Fodpfxsxxi Ewe Ag Ajft Max. diameter ( non adjacent tool ) 135 mm, Max. tool length 250 mm,Max. tool weight 6.5Kg, Time to change tool 3sg. Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 30 kVA Dimensions # floor space required : aprox.L 2.1 x l 3.5 x H 3m # weight : aprox 4200 kg Equipment consist of: # CNC control GE Fanuc Series 31i MODEL A # CHIPS EXTRACTOR # LUBRICATION SYSTEM # COOLING SYSTEM ELECTRICAL PANEL, # SPINDLE COOLING SYSTEM : HARBOR Model:HBO-750PTSB2 # Documentation : Electronic available / Book available Machine status : NOT WORKING # Motor Y axis broken - to be replaced - not repairable # Tool exchanger 2 units broken - to be replaced - not repairable # Spindles broken - to be replaced - not repairable # Hydraulic group broken - to be replaced or repaired

Condiție: foarte bun (second hand), 077 MALAXOR SPIRAL SH UTILIZAT + 2 cuve din inox. Mașina este funcțională. DATE TEHNICE: - capacitate: 200 kg aluat, - 125 kg făină. Fjdpfx Asx Sqqqeg Aeft DIMENSIUNI EXTERIOARE (în cm): - lățime: 95, - lungime: 145, - înălțime: 130 DIMENSIUNI CUVA (în cm): - lățime: 95, - înălțime: 83,5 - adâncime: 49,5, - lățime interioară: 90. Echipamentul este pregătit pentru vizionare în depozitul nostru (36-068 Bachórz, Polonia). Opțiuni suplimentare contra cost: transport / montaj / punere în funcțiune. Prețul indicat este net. VORBIM ENGLEZĂ, GERMANĂ, FRANCEZĂ, RUSĂ, UCRAINEANĂ. În oferta noastră veți găsi: cuptoare de panificație, cuptoare rotative, cuptoare pe etaje, cuptoare pentru patiserie, cuptoare pentru magazine, utilaje de panificație, linii pentru pâine, linii pentru chifle, linii pentru prăjituri, linii pentru croissante, mașini pentru baghete, malaxoare, mixere, laminatoare, modelatoare pentru cornuri. Vedeți toate anunțurile noastre.

Condiție: foarte bun (second hand), De vânzare: portsculă profesională WNT SK40 Ø12x80, potrivită pentru lucrul la până la 25.000 rpm (echilibrare G2.5). Portscula este livrată completă cu burghiu ventilat – ideal pentru prelucrare cu răcire internă. Stare foarte bună, scula verificată, gata de lucru. Echipament de top, destinat prelucrărilor de precizie pe centre CNC. Ffsdow Rrw Uspfx Ag Ajt

Condiție: folosit, Anul fabricației: 2009, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: B-8023, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 Kg) # Nº of T.Slots:3/Distance between T.Slots: 125 mm/Width of T.Slots: 18 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) +2 twin horizontal spindles + 4 th Axis # Rapid speed : X,Y,Z - 30m/min # Work travel : Longitudinal travel (x-axis) 600 mm,Cross Travel (y-axis) 400 mm,Vertical Travel (z-axis) 510 mm Headstock capabilities: # Spindles distance : 200 mm # Max. distance from spindle to table 650 mm # Spindle nose: ISO7388 (with internal refrigeration),Tool Holder (Size 40) # Speed range (standard)100/8000,Maximum torque / at 330 rpm,85 Nm ,7.5 kw Automatic tool changer: # Number of tools :20 ,Selection system:Sequential-/random,Max. diameter (adjacent tool)85 mm, Max. diameter ( non adjacent tool ) 135 mm,Max. tool length 250 mm,Max. tool weight 6.5 Kg,Time to change tool 6 sg. Time to change tool 3sg. Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 30 kVA Dimensions # floor space required : aprox. L 2.1 x l 3.5 x H 3m # weight : aprox 4200 kg Equipment consist of: # CNC control GE Fanuc Series 31i MODEL A # 4th axis : Nikken CNC180 FA (2012) # broken tool detection system : BlumNovotec # CHIPS EXTRACTOR # LUBRICATION SYSTEM # COOLING SYSTEM ELECTRICAL PANEL, # SPINDLE COOLING SYSTEM : HARBOR Model:HBO-750PTSB2 # Documentation : Electronic available / Book available Machine status : WORKING - with 1 spindle / 2nd spindle broken - can be repaired. Fsdpfxsxxi Ske Ag Aoft

Condiție: folosit, Anul fabricației: 2017, Funcționalitate: complet funcțional, număr mașină/vehicul: 17KX216770001, Technical characteristics: Work Area # Maximum turning diameter: 230 mm (with loader 120 mm) # Maximum machining diameter: 200 mm # Maximum workpiece length: 145 mm (with loader 75 mm) # X1/X2 - axis travel distance: 130 mm / Rapid speed in X: 24 m/min # Z1/Z2 -axis travel distance: 145 mm / Rapid speed in Z: 24 m/min # Y1/Y2-Axis travel distance: +/-40mm / Rapid speed in Z: 12 m/min Automation: # Axis Stroke: X - Left 200 mm / Right 1600 mm ; Y - 550 mm ; Z - 155 ; α 180˚ # Max speeds m/min : X - 160 ; Y - 120 ; Z - 35 mm ; α 180˚/1sec # Specification of load / unload grippers (air pressure powered) : outer diameter - Ø90; jaw stroke 30 mm ; gripping force : outside 128 kgf / inside 138 kgf Main Spindle # Spindle size : Standard (6 / 8 inches)/165 mm/205 mm # Maximum speed: Left & right 45-4500 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW Tool Holder with Motorized Tools # Tool Interface: BMT55 # Number of position : 12right / 12left-station disc turret, all driven positions # Maximum speed: max 4000 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 200Vx3, fusible 151A # Connection power: 31 kVA Dimensions # Machine Dimensions (L×W×H): 3950 ×2715× 2800 mm # Weight : 4400 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, loading/unloading by gantry from conveyors # Automation consist of : Gantry robot + 2 loading unloading conveyors # CNC Control: Fanuc FS31i Model A Series # Chip extraction conveyor # Coolant filtration 40 bar max: Micron Filter, model Evotech 500PRO # Coolant cooling: T exa TCW55PMSBCDX00 sn165373 # Control in process: Marposs T25 # Broken tool detection system: Peek tool menu Murata/Fanuc feature activated # Documentation : Electronic available / Book available Machine status : Ffsdpfjxxi Ncsx Ag Aet WORKING

Condiție: necesită reparații (utilizat), Anul fabricației: 2007, Funcționalitate: nefuncțional, număr mașină/vehicul: 191-89, Technical characteristics: Fodexxi Rmepfx Ag Ajft # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1axel of rotation table A and 2 axis of rotation B with index divider head with direct measuring system angular with no of rev. 50 minˉ¹ , precision +/- 5" # Axis A swivel : +/-110˚ # Max. dimension clamping / part : Ø 247 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 40/40/40 m/min , # Distance between Divider heads B1/B2 : 250 mm # Spindle speed 1-10000 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 1x48 tools / chip to chip medium 2.5 sec # Tool max. Ø82 mm / long. Max.250 mm / 5kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 45 kVA / 80A Dimensions # installation space : aprox. 4.4 x 2.3 x 3.1 m # weight : aprox 8500 kg Equipment consist of: # CNC control : Siemens 840D Power line # CHIPS EXTRACTOR Spring Knoll # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll HL 450/1200 # SHAFT COOLING SYSTEM, GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : LTA # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: not complete Machine status : NOT WORKING # Motor for hydraulic unit burn out

Condiție: folosit, Anul fabricației: 2017, Funcționalitate: complet funcțional, număr mașină/vehicul: 109239, Technical characteristics: Work Area # Chuck diameter: 260 mm # Weight max. : 150 Kg # Swing diameter: 280 mm # Workpiece dia. / height max.: 200/200 mm # X stroke(working stroke): 760 mm / Rapid speed in X: 60 m/min / feed force 6.9 kN # Z stroke: 415 mm / Rapid speed in Z: 30 m/min / feed force 18.7 kN # Loading time : 5÷6 sec # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 25 / 18 kW # Torque with 100 / 40% duty cycle: 280 / 200 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 Ffjdpfoxxir Djx Ag Ast # Number of position : 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,100 A # Connection power: 36 kVA Dimensions # Total dimensions: Length=5300 with chip extractor,Wide=2300 mm,Height=3650 mm # Weight : 9000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Emag O-Type Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor&coolant filtration unit Micron filter with ''paper filter'' with 40 Bar pumps(capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : WORKING

Condiție: necesită reparații (utilizat), Anul fabricației: 2009, Funcționalitate: nefuncțional, număr mașină/vehicul: 281-06, Technical characteristics: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Axis A swivel : +/-110˚ # Max. dimension clamping / part : Ø 247 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 40/40/40 m/min , # Distance between Divider heads B1/B2 : 250 mm # Spindle speed 1-10000 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 1x48 tools / chip to chip medium 2.5 sec # Tool max. Ø82 mm / long. Max.250 mm / 5kg Ffodpfx Agoxxivco Ajt Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 45 kVA / 80A Dimensions # installation space : aprox. 4.4 x 2.3 x 3.1 m # weight : aprox 8500 kg Equipment consist of: # CNC control : Siemens 840D Power line # CHIPS EXTRACTOR Spring Knoll # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll HL 450/1200 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : LTA AC3002 # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage : Blum Novotech # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: not complete Machine status : NOT WORKING # door for tool magazine # tool magazine presence sensor (BERU)

Condiție: necesită reparații (utilizat), Anul fabricației: 2007, Funcționalitate: nefuncțional, număr mașină/vehicul: 191-88, Technical characteristics: Ffodpfx Aoxw Upleg Aot # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Axis A swivel : +/-110˚ # Max. dimension clamping / part : Ø 247 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 40/40/40 m/min , # Distance between Divider heads B1/B2 : 250 mm # Spindle speed 1-10000 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 1x48 tools / chip to chip medium 2.5 sec # Tool max.Ø82 mm / long. Max.250 mm / 5kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 45 kVA / 80A Dimensions # installation space : aprox. 4.4 x 2.3 x 3.1 m # weight : aprox 8500 kg Equipment consist of: # CNC control : Siemens 840D Power line # CHIPS EXTRACTOR Spring Knoll # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll HL 450/1200 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : LTA AC3002 # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: not complete Machine status : NOT WORKING # Operator protection display broken - Operator panel working # Tool Magazine chain # Ballbar X # Ballbar Y # Pullbar spindle # Driver power source X # Driver power source Y # General power source drivers # Complete hyddraulic unit broken

Condiție: necesită reparații (utilizat), Anul fabricației: 2007, Funcționalitate: nefuncțional, număr mașină/vehicul: 1830108, Technical characteristics: # Machining Workspace: X 300 mm; Y 650 mm; Z 400 mm # Axis description: 3 LINIAR AXIS (X,Y,Z) +1 axel of swivel table A360 [degrees] indexable divider head (resolution 0.001˚) # Number of pallets : 2 Max . Table load 400 Kg # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 75/75/75 m/min , Position precision Tp : 0.008 mm # Number of spindles : 2 / with distance between spindles: 300 mm # Spindle speed 1-10000 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Fodpfx Ajxw Ukvog Aoft Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 70 kVA / 125A Dimensions # installation space : aprox. 3.9 x 3.2 x 3.1 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Fanuc 30i-Model A # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 40 Bar : Knoll AE 1060 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # Part presence P/Y : with low pressure air detectors # Broken tool detection : Blum Novotec Laser Light probe # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : NOT WORKING # Magasine chain broken - NEED TO BE REPLACED

Condiție: folosit, Anul fabricației: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460065, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A and 2 axis of rotation B with index divider head with direct measuring system angular with no of rev. 50minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll 550 K-1 450_2450 (!!! Can serve 2 machines at once) # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) # Documentation: Only books available Machine status : Ffodpjxw Ttijfx Ag Aet WORKING

Condiție: folosit, Anul fabricației: 2010, Funcționalitate: complet funcțional, număr mașină/vehicul: B-8044, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor:850 mm (max load 450 Kg) # Nº of T.Slots:3/Distance between T. Slots: 125 mm/Width of T. Slots: 18 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 4 th Axis # Rapid speed : X,Y,Z - 30m/min # Work travel : Longitudinal travel (x-axis) 600 mm,Cross Travel (y-axis) 400 mm,Vertical Travel (z-axis) 510 mm Headstock capabilities: # Max. distance from spindle to table 650 mm # Spindle nose: ISO 7388 (with internal refrigeration),Tool Holder (Size 40) # Speed range (standard)100/14000,Maximum torque / at 330 rpm,63.7/89.4 Nm Automatic tool changer: # Number of tools :20 ,Selection system:Sequential-/random,Max. diameter (adjacent tool) 85 mm, Max. diameter ( non adjacent tool ) 135 mm,Max. tool length 300 mm,Max. tool weight 6.5 Kg,Time to change tool 6 sg. Time to change tool 3sg. Electrical connection: Fedpfx Agexw Tqzj Aeft # tension: 3x400V/50Hz # Power installed: aprox 30 kVA Dimensions # floor space required : aprox. L 2.1 x l 3.5 x H 3m # weight : aprox 4200 kg Equipment consist of: # CNC control GE Fanuc Series 31i MODEL A # CHIPS EXTRACTOR # LUBRICATION SYSTEM # Emulsion''paper'' filtering system: Filber S.L. Model FTH5/10 200l/min # COOLING SYSTEM ELECTRICAL PANEL, # SPINDLE COOLING SYSTEM : HARBOR Model:HBO-750PTSB2 # Documentation : Electronic available / Book available Machine status : WORKING

Condiție: folosit, Anul fabricației: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 2460062, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A index divider head with direct measuring system angular with no of rev. 50 minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # installation space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales Ffodpfx Agexw Syuo Aet # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # OIL filtering system max 80 Bar : Knoll VRF 450_2350 # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : IFS Vario E2000 (2000m3/H) # Antifire : Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : WORKING

Condiție: necesită reparații (utilizat), Anul fabricației: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 2460061, Technical characteristics: # Machining Workspace: X 300 mm; Y 500(725) mm; Z 375 mm # Axis description: 3 LINIAR AXIS(X,Y,Z) + 1 axel of rotation table A + indexable divider head with direct measuring system angular with no of rev. 50 minˉ¹ , precision +/- 5" # Max. dimension clamping / part : Ø 575 x 830 mm; weight max 360 Kg # Rapid speed : X/Y/Z 65/75/75 m/min , Position precision Tp : 0.008 mm # Distance between spindles: 300 mm # Spindle speed 1-17500 rpm # Spindle nose: DIN69893-HSK-A63 (with internal refrigeration) # Automatic tool changer 2x32 tools / chip to chip medium 2.5 sec # Tool max. Ø75 mm / long. Max.275 mm / 7.5 kg Electrical connection: Fsdpfx Aexw R Udeg Aeft # tension: 3x400V/50Hz # Power installed: aprox 85 kVA / 125A Dimensions # instalaltion space : aprox. 3.6 x 6 x 3.7 m # weight : aprox 10500 kg Equipment consist of: # CNC control : Siemens 840D SL # Liniar axis measuring device : Heindenhain liniar scales # CHIPS EXTRACTOR Knoll Type 550 K-1 # OIL COOLING SYSTEM # SHAFT COOLING SYSTEM,GUIDES AND SWITCHBOARD # 2 OIL LUBRICATION SYSTEMS # OIL VAPOR ABSORPTION/RECOVERY SYSTEM : ELBARON Vario E2000 (2000m3/H) # OIL filtering system with paper filter max 80 Bar : Knoll KF200/1200 # Antifire: Kraft& Bauer # Part presence P/Y : with low pressure air detectors # Control in process: Marposs T25 # Control tool breakage system BRK and length checker: inductive sensor # TOOL SUPPORT DETECTION SYSTEM IN THE WORK SHAFT(spindle) Machine status : NOT WORKING # Motor door loading unloading # Table A axis # Tool Magazine Chain # Safety switch Euchner loading door # Hydraulic switches 5 units ( Parker) # Pneumatic pistons for tool magazine access 2 units # Pneumatic pistons for tool clamping 2 units # Hydraulic system complete # Motor for Hydraulic motor ( can be also retrofited ) # Compressed air regulator # Chip conveyor extractor - need to be repaired # Liniar scale z axis # Liniar scale X axis # Numerical Control flash card # Communication modules Murr 4 units # 1 of 2 spindles broken - on stock to be installed
