Conveioare Verticale cumpărați folosit (8.575)

Stare: necesită reparații (utilizat), An de fabricație: 2014, Funcționalitate: nefuncțional, număr mașină/vehicul: 67137, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 250 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 886 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: -85/+100 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle (Weiss) according to DIN 55026: Size A6 # Maximum speed: 5500 rpm # Power with 100% OT: 38 kW # Torque with 100% OT : 300 Nm Secondary Spindle HSK63 # Spindle Head Size/type :HSK-A63 # Nominal speed: 2700 rpm / Nominal Power 12 kw /nominal torque 42.4 Nm # Maximum speed: 15000 rpm # Power with 100% OT: 38 kW # Torque with 100% OT : 300 Nm Tool Holder with Motorized Tools # turret VDI40, Siemens-drive 0.5.440.220 Fabr. Sauter # Number of position : 12 # Life tool nominal speed : 3000 U/min , nominal torque 33.1 Nm # Life tool maxim speed : 10000 U/min , nominal torque 56.2 Nm # Life tool nominal power 100% OT : 10.4 Kw Electrical Equipment # Operating voltage: 400 V, fusible 100A GL # Connection power: 45 kW Dimensions # Total dimensions: Length=4021 mm,Wide=4709 mm,Height=3527 mm # Weight : 8000 Kg Main Features and Capabilities: Godsxxi Urjpfx Ahyetw # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z,Y Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Secondary Spindle Weiss: High power and wide speed range.( easy access for drilling/milling operations ) # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/500 # Electrostatic mist filter : IFS type IFM1000 Machine status : NOT WORKING # Sauter turret replaced with new one, assembly process not finished - assembly of turret motor spindle to be finished # safety switch of Operator panel need to be replaced

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 46003, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 220 mm # Maximum turning diameter: 170 mm # Maximum machining diameter: 170 mm # Maximum workpiece length: 100 mm # X-axis travel distance: 495 mm / Rapid speed in X: 48 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 7000 rpm # Power with 100% OT: 23 kW # Torque with 100% OT :130 Nm Tool Holder with Motorized Tools Gtsdjxw Ub Ijpfx Ahyow # turret VDI40, Siemens-drive 0.5.435.220 Fabr. Sauter # Number of position : 12 # Maximum speed: 4000 rpm Electrical Equipment # Operating voltage: 400 V, fusible 80A GL # Connection power: 41 kW Dimensions # Total dimensions: Length=3913 mm,Wide=2160 mm,Height=2955 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyur : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/950 # Fire extinguisher : Kraft&Bauer # Electrostatic mist filter : IF Vario EC1500 Machine status : WORKING

Stare: folosit, An de fabricație: 2011, Funcționalitate: complet funcțional, număr mașină/vehicul: 102821, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 250 mm # Maximum turning diameter: 270 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 175 mm # X-axis travel distance: 660 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 300 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 V # Connection power: 36 kW / 80A Dimensions # Total dimensions: Length=3120 mm(4185 with chip extractor),Wide=2266 mm,Height=3200 mm # Weight : 7500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc Series 32i Model A. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Part detection sensor with compressed airgage throw spindle :SMW Autoblock Linear Position Sensor LPS-X # Control in process: Marposs T25 # Chip extraction conveyor # Documentation : Electronic & Book available Machine status : Gtedpfsxxikgex Ahysw WORKING

Stare: folosit, An de fabricație: 2016, Funcționalitate: complet funcțional, număr mașină/vehicul: 46001, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 220 mm # Maximum turning diameter: 170 mm # Maximum machining diameter: 170 mm # Maximum workpiece length: 100 mm # X-axis travel distance: 495 mm / Rapid speed in X: 48 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 7000 rpm # Power with 100% OT: 23 kW # Torque with 100% OT :130 Nm Tool Holder with Motorized Tools # turret VDI40, Siemens-drive 0.5.435.220 Fabr. Sauter # Number of position : 12 # Maximum speed: 4000 rpm Electrical Equipment # Operating voltage: 400 V, fusible 80A GL # Connection power: 41 kW Dimensions # Total dimensions: Length=3913 mm,Wide=2160 mm,Height=2955 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/950 # Fire extinguisher : Kraft&Bauer # Electrostatic mist filter : IF Vario EC1500 Machine status : Gtjdsxw Ufyspfx Ahyow WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2017, Funcționalitate: nefuncțional, număr mașină/vehicul: 179057653, Technical characteristics: Work Area # Chuck diameter: 600 mm Gtodoxxinfspfx Ahyow # Workpiece dia. / height max.: 450 / 400 mm # Distance spindle nose vs. origin tails stock : 639 mm # X1/X2 stroke(working stroke): 335/289 mm / Rapid speed in X: 30 m/min # Z1/Z2 stroke: 560/494 mm / Rapid speed in Z: 30 m/min # Standard closed with automatic door opening - manual or automatic loading option Main Spindle # Spindle according to DIN 55026: Size A6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 23 / 18 kW # Torque with 100 / 40% duty cycle: 146 / 115 Nm Tails stock # Interface: MK4 # Clamping force: 850 daN # Clamping stroke: 200 mm Turret config X1/Z1 : Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 8 - VDI40 # Max Tool Length : 130 mm # Number of position : 1 x 8 # Maximum speed: 4500 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Turret config X2/Z2 : Tool Holder with Motorized Tools # X-HOT unit for polygonal shapes machining max. eccentricity (Stroke): 8 mm # X-HOT Clamping system tool holder : HSK 32S Electrical Equipment # Operating voltage: 400 V ,100 A # Connection power: 37 kVA Dimensions # Total dimensions: Length=3000(6477 with chip extractor),Wide=3000 mm,Height=3650 mm # Weight : 11000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation ,manual or automatic loading/unloading. # Control: Siemens 840D controlling NC1 and NC2 # High Precision: Positioning accuracy in X,Z axes is ±0.002 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring # Chip conveyor Coolant : Knoll # Coolant filtration unit max 40Bar : Knoll FKA/1400 # Part presence detection sistem : with low air presure detector # AUTOMATION INFRASTRUCTURE FOR ROBOT INSTALLED # Fully enclosed work area Light in working area # Documentation : Electronic available & Book available Machine status : Not working # missing valve for emulsion circuit and inductive sensors

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107965, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions Gtedpfjxw Svisx Ahyjw # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor & coolant filtration unit Knoll with ''paper filter'' with 40 Bar pumps ( capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Life tool Motor # Loading door Safety Euchner # Turret Motor # Driver turret Motor # Oiling pump # Hydraulic block electrovalvula x4 units # Oiling pressure # Rotary joint # Loading door hydraulic cylinder # Spindle clamp/unclamp sensor

Stare: folosit, An de fabricație: 2015, Funcționalitate: complet funcțional, număr mașină/vehicul: 106679, Technical characteristics: Work Area # Chuck diameter: 260 mm # Weight max. : 150 Kg # Swing diameter: 280 mm # Workpiece dia. / height max.: 200/200 mm # X stroke(working stroke): 760 mm / Rapid speed in X: 60 m/min / feed force 6.9 kN # Y stroke: +/-30 mm / Rapid speed in X: 15 m/min / feed force 7.5 kN # Z stroke: 415 mm / Rapid speed in Z: 30 m/min / feed force 18.7 kN # Loading time : 5÷6 sec # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 25 / 18 kW # Torque with 100 / 40% duty cycle: 280 / 200 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,100 A # Connection power: 36 kVA Dimensions # Total dimensions: Length=5300 with chip extractor,Wide=2300 mm,Height=3650 mm # Weight : 9000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. Gjdpfsxw Smbox Ahyjtw # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Emag O-Type Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor&coolant filtration unit Micronfilter with ''paper filter'' with 40 Bar pumps(capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107964, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: Gtjdpfoxw Srkex Ahysw # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Cooling Pump x2 units # Life Tool Motor # Oiling Pump # Operator panel - touch screen need to be changed # Hydraulic block valves x 3 units # Hydraulic cylinder loading door # Rotary Joint # Oiling Pressure switch # Safety door Euchner

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107786, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Gedpfx Ahsxw Slkjyjtw Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Operator panel - touch screen need to be changed # Hydraulic cylinder loading door broken # Emulsion Pump # Hydraulic pump # Spindle clamp unclamp sensor # Hydraulic pressure accumulator # Turret motor

Stare: folosit, An de fabricație: 2014, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: 179057784, Technical characteristics: Work Area # Chuck diameter: 600 mm # Workpiece dia. / height max.: 450 / 400 mm # Distance spindle nose vs. origin tailstock : 639 mm # X1/X2 stroke(working stroke): 335/289 mm / Rapid speed in X: 30 m/min # Z1/Z2 stroke: 560/494 mm / Rapid speed in Z: 30 m/min # Standard closed with automatic door opening - manual or automatic loading option Main Spindle # Spindle according to DIN 55026: Size A6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 23 / 18 kW # Torque with 100 / 40% duty cycle: 146 / 115 Nm Tailstock # Interface: MK4 # Clamping force: 850 daN Gtodpfxsxw R Rfe Ahyow # Clamping stroke: 200 mm Turret config X1/Z1 : Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 8 - VDI40 # Max Tool Length : 130 mm # Number of position : 1 x 8 # Maximum speed: 4500 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Turret config X2/Z2 : Tool Holder with Motorized Tools # X-HOT unit for poligonal shapes machining max. eccentricity (Stroke): 8 mm # X-HOT Clamping system tool holder : HSK 32S Electrical Equipment # Operating voltage: 400 V ,100 A # Connection power: 37 kVA Dimensions # Total dimensions: Length=3000(6477 with chip extractor), Wide=3000 mm,Height=3650 mm # Weight : 11000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation ,manual or automatic loading/unloading. # Control: Siemens 840D controlling NC1 and NC2 # High Precision: Positioning accuracy in X,Z axes is ±0.002 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring # Chip conveyor Coolant : Knoll # Coolant filtration unit max 40Bar : Knoll FKA/1400 # Part presence detection system : with low air pressure detector # AUTOMATION INFRASTRUCTURE FOR # ROBOT INSTALLED # Fully enclosed work area Light in working area # Documentation : Electronic available & Book available Machine status : WORKING only X1/Z1 - X2/Z2 working, but no XHOT available

Stare: bun (utilizat), An de fabricație: 2011, Funcționalitate: complet funcțional, număr mașină/vehicul: 179056920, Technical characteristics: Work Area # Chuck diameter: 600 mm # Workpiece dia. / height max.: 450 / 400 mm # Distance spindle nose vs. origin tailstock : 639 mm # X1/X2 stroke(working stroke): 335/289 mm / Rapid speed in X: 30 m/min # Z1/Z2 stroke: 560/494 mm / Rapid speed in Z: 30 m/min # Standard closed with automatic door opening - manual or automatic loading option Main Spindle # Spindle according to DIN 55026: Size A6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 23 / 18 kW # Torque with 100 / 40% duty cycle: 146 / 115 Nm Tailstock # Interface: MK4 # Clamping force: 850 daN # Clamping stroke: 200 mm Turret config X1/Z1 : Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 8 - VDI40 # Max Tool Length : 130 mm # Number of position : 1 x 8 # Maximum speed: 4500 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Turret config X2/Z2 : Tool Holder with Motorized Tools # X-HOT unit for poligonal shapes machining max. ECCENTRICITY (Stroke): 8mm # X-HOT Clamping sistem tool holder : HSK 32S Electrical Equipment # Operating voltage: 400 V ,100 A # Connection power: 37 kVA Dimensions # Total dimensions: Lenght=3000(6477 with chip extractor),Wide=3000 mm,Height=3650mm # Weight : 11000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation ,manual or automatic loading/unloading. # Control: Siemens 840D controlling NC1 and NC2 # High Precision: Positioning accuracy in X,Z axes is ±0.002 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring # Chip conveyor Coolant : Knoll # Coolant filtration unit max 40Bar : Knoll FKA/1400 # Part presence detection sistem : with low air presure detector # AUTOMATIOZATION INFRASTRUCTURE FOR # ROBOT INSTALLED Gtjdpfoxwmf Sjx Ahysw # Fully enclosed work area Light in working area # Documentation : Electronic available & Book available Machine status : WORKING

Stare: bun (utilizat), An de fabricație: 2008, Funcționalitate: complet funcțional, număr mașină/vehicul: 101868, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools Gtodpfx Ahjxwk U Dsyjw # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Lenght=2680mm(3820 with chip extractor),Wide=2040 mm,Height=2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2006, Funcționalitate: nefuncțional, număr mașină/vehicul: 00592, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 200 mm # Maximum machining diameter: 130 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 400 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 7500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 3x 400 - 480 V , 50A # Connection power: 31 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available / Book available Gtedpfexwlbxex Ahyow Machine status : NOT WORKING # Motor from Life tool broken # Reductor from life tool broken

Stare: necesită reparații (utilizat), An de fabricație: 2009, Funcționalitate: nefuncțional, număr mașină/vehicul: 101851, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Gtjdpoxvy Azjfx Ahyjw Machine status : NOT WORKING # Motor from Lifetool # Optical scale X axis broken + connection cable # Belt Z axis # Oiling Presostat # Hidraulic main pressure valve # Door safety Euchner

Stare: necesită reparații (utilizat), An de fabricație: 2011, Funcționalitate: nefuncțional, număr mașină/vehicul: 68178, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 626 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 250mm / Rapid speed in Z: 30 m/min # Standard closed work piece automation by Gantry loader from individual nests conveyor highway Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 5500 rpm # Power with 100% ED : 38 kW # Torque with 100 % ED: 300 Nm Tool Holder with Motorized Tools # Tool Interface: VDI40 DIN 5480 Gedpfxsxwk Iws Ahyjtw # Number of position : 12-station disc turret, all driven positions # Maximum speed: 6000 rpm, Torque Capacity: 70–100 Nm per driven station Electrical Equipment # Operating voltage: 2x400, fusible 160A GL # Connection power: 90 kW Dimensions # Total dimensions: Length =3390mm,Wide=2850 mm, Height=2400mm # Weight : 16000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z axes by Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools by Sauter turret: The possibility of using live tools extends the machining range to include drilling and milling. # Cooling & ''paper'' filtering unit : DGS System GMBH 950L # Chip extraction conveyor : DGS System GMBH # Hydraulic unit : Rexroth Q=13 l/min , pmax=65 bar # Mist extraction units : IFS model IFM1000 # Documentation availability : Yes. Machine status : NOT WORKING # Loading/unloading slide ways doors defective # Liniar scale X axis 2 units # Turret position sensor (furT30) # Sensor Clamp Unclamp Spindle # Electro valve emulsion - 4 units

Stare: necesită reparații (utilizat), An de fabricație: 2011, Funcționalitate: nefuncțional, număr mașină/vehicul: 66101, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 626 mm / Rapid speed in X: 60 m/min Godjxwk S Aspfx Ahyetw # Z-axis travel distance: 250mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: +100/-90 mm / Rapid speed in Y: 30 m/min # Standard closed work piece automation Pick-up station from individual nests conveyour highway Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 5500 rpm # Power with 100% ED : 38 kW # Torque with 100 % ED: 300 Nm Tool Holder with Motorized Tools # Tool Interface: VDI40 DIN 5480 # Number of position : 12-station disc turret, all driven positions # Maximum speed: 6000 rpm, Torque Capacity: 70–100 Nm per driven station Electrical Equipment # Operating voltage: 2x400, fusible 160A GL # Connection power: 90 kW Dimensions # Total dimensions: Lenght=3390mm,Wide=2850 mm,Height=2400mm # Weight : 16000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools by Sauter turret: The possibility of using live tools extends the machining range to include drilling and milling. # Cooling & ''paper'' filtering unit : DGS System GMBH 950L # Chip extraction conveyor : DGS System GMBH # Hydraulic unit : Rexroth Q=13 l/min , pmax=65 bar # Mist extraction units : IFS model IFM1000 # Documentation availability : Yes. Machine status : NOT WORKING # Pick-up pneumatic cylinder # Turret indexation motor # Closing door pneumatic piston # Door safety Euchner switch # Liniar scale Z axis # Siemens Power source

Stare: necesită reparații (utilizat), An de fabricație: 2008, Funcționalitate: nefuncțional, număr mașină/vehicul: 101850, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment Gsdpfxjxvyh Re Ahyotw # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc Series 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : NOT WORKING # Motor from Life tool # Optical scale X axis # Optical scale Z axis # Belt Z axis # Driver unit Z-X axis # Cable Optical scale axis X,Z # Emulsion Pump

Stare: necesită reparații (utilizat), An de fabricație: 2012, Funcționalitate: nefuncțional, număr mașină/vehicul: 103563, Technical characteristics: Work Area: # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle: # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens Sinumerik 840D-sl. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : NOT WORKING # Motor from Life tool - dismantled from machine # Spindle broken - dismantle from machine # Turret dismantled ( leakage if cooling coolant throw refrigeration circuit of turret ) Gsdpfx Ahjxvyk Eoyetw

Stare: folosit, An de fabricație: 2008, Funcționalitate: complet funcțional, număr mașină/vehicul: M250.81009, Technical characteristics: # Main Drive: * Connected Load: 400 V/50 Hz / 43 kW * Drive Power of Main Spindle (100% ED / 40% ED): 18 kW / 28 kW * Main Spindle Torque: 300 Nm * Speed Range: 0-4500 rpm * Spindle Head: DIN 55026-A6 # Working Area:Rapid Traverse X-axis: 60 m/min * Rapid Traverse Z-axis: 30 m/min * Feed Force X-axis: 10 kN * Feed Force Z-axis: 10 kN # Control: * Siemens SINUMERIK 840Dsl * 15-inch TFT Monitor. # Working Accuracy: * Axes (X-axis / Z-axis): ±0.001 mm * Spindle (C-axis): ±0.01° # Tool Carrier: * EMAG Flange Turret Generation C361 - Capto C5. *. * Holder Shank Diameter: TN340009 * Max. Tool Dimensions: Workpiece-dependent. * Tool Change Times (Turret / Live Tool): 0.03 min / 0.04 min. * Max. Speed of Live Tool: 6000 rpm. * Max. Torque of Live Tool (100% ED / 10% ED): 15 Nm/3.5 kW / 40 Nm/8.5 kW. # Coolant System: * Standard Delivery Pressure / Max. Delivery Pressure: 7 bar * Pressure Range of Internal Coolant Supply: 7 bar (not adjustable) * Coolant Tank Capacity: 360 liters # Part Catcher: * No part catcher available. Parts are fed to and removed from the machine via automation. Ambient Conditions (Room temperature / Air humidity): up to approx. 30°C / max. 50% * Noise Level (Sound Pressure Level / Sound Power Level): 78 dB(A) # General: * Machine Dimensions (L x W x H): 3900 mm x 1500 mm x 3200 mm * Machine Weight: approx. 7000 kg * Gtjdpfxexvx T Ss Ahyjw Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens SINUMERIK 840Dsl with integrated PLC S7-300 and a 15-inch TFT monitor. # High Precision: Positioning accuracy in X and Z axes is ±0.001 mm. # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip conveyour # Chuck installed : EMB3 Expanding mandril Autoblock # Capto C5 tool holders installed on turret ( External/internal machining 2 units & 2 lifetools ) # Tool load monitor Artis capability available

Stare: gata de utilizare (folosit), An de fabricație: 2003, Unitate de comandă Brand: FANUC Gtedpfjx D Dygjx Ahysw Model: Seria 18i-MB Date generale Greutate maşină: 4500 kg Înălţime: 2700 mm Dimensiuni Lungime maşină: 3300 mm Masă Sarcină maximă pe masă: 500 kg Lăţime masă: 1200 mm Lungime masă: 600 mm Unitatea principală de acţionare Număr axe: 3 Turaţie arbore principal: 10.000 rpm Putere motor arbore principal: 9 kW Prindere sculă: SK 40 Scule Greutate maximă sculă: 8 kg Deplasări Cursă axă X: 1000 mm Cursă axă Z: 500 mm Cursă axă Y: 600 mm Acest centru de prelucrare verticală DECKEL MAHO DMC 103V cu 3 axe a fost fabricat în 2003. Este echipat cu comandă CNC FANUC Seria 18i-MB şi are curse pe axe de 1000 mm pe X, 600 mm pe Y şi 500 mm pe Z. Arborele principal este prevăzut cu prindere SK40, atinge 10.000 rpm, iar masa suportă piese de până la 500 kg. Profitaţi de oportunitatea de a achiziţiona acest centru de prelucrare verticală DECKEL MAHO DMC 103V. Pentru mai multe informaţii despre această maşină, vă rugăm să ne contactaţi. Domenii de utilizare Frezare

Stare: gata de utilizare (folosit), An de fabricație: 2007, Date generale Greutatea utilajului: 7500 kg Gedpex R E Izjfx Ahyotw Unitate de control Marcă: SIEMENS Model: SINUMERIK 810D powerline și ShopMill Acționare principală Interval turații ax principal: 50–12000 rpm Con portsculă: SK40 Număr de axe: 3 Deplasări Deplasare axă X: 640 mm Avans rapid axă X: 70 m/min Deplasare axă Y: 600 mm Avans rapid axă Y: 40 m/min Deplasare axă Z: 500 mm Avans rapid axă Z: 40 m/min Masă Sarcină maximă masă: 600 kg Această freză CNC pe 3 axe DMG DECKEL MAHO DMC 64V linear a fost fabricată în 2007. Echipată cu comandă Siemens 810D ShopMill, ax principal SK40 cu turații de până la 12.000 rpm și magazie de unelte cu 30 de poziții. Mașina dispune de transportoare de șpan, pistol pentru răcire și sistem de răcire la presiune înaltă. Ideală pentru prelucrări precise și eficiente. Contactați-ne pentru mai multe detalii despre această mașină. Tipuri de aplicații Frezare

Stare: gata de utilizare (folosit), An de fabricație: 2012, Unitate de control Model: Seria 0iMD Marcă: FANUC Acționare principală Turație arbore principal: 1000 rpm Număr de axe: 4 Deplasări Deplasare pe axa X: 1600 mm Deplasare pe axa Y: 800 mm Deplasare pe axa Z: 800 mm Gtodpfx Ajx D S Dtehyew Masă de lucru Lungime utilă: 1700 mm Lățime utilă: 800 mm Sarcina maximă pe masă: 2000 kg Echipamente suplimentare Opțiuni incluse: Axă a 4-a Acest centru de prelucrare vertical cu 4 axe AWEA AF-1600 a fost fabricat în 2012. Dispune de o masă de dimensiuni mari, 1700 mm x 800 mm, cu o capacitate de încărcare de 2000 kg și o turație a arborelui principal de 1000 rpm. Echipat cu unitate de comandă Fanuc Seria 0iMD și un magazin de scule cu 16 poziții, utilajul AWEA AF-1600 pe care îl oferim spre vânzare este ideal pentru operațiuni complexe de prelucrarare. Pentru informații suplimentare despre acest centru de prelucrare vertical, vă rugăm să ne contactați. Domenii de aplicare Frezare

Stare: gata de utilizare (folosit), An de fabricație: 2020, Unitate de control Gtjdsx Enh Tjpfx Ahysw Marca: HAAS Model: NGC Acționare principală Număr de axe: 3 Mișcare Cursa pe axa X: 1270 mm Cursa pe axa Z: 635 mm Cursa pe axa Y: 508 mm Acest centru de prelucrare vertical cu 3 axe HAAS VF-4 a fost fabricat în 2020. Dispune de o cursă pe axa X de 1270 mm, axa Y de 508 mm și axa Z de 635 mm, suportând o sarcină pe masă de până la 1588 kg. Echipat cu un magazin de scule cu 20 de posturi, extractor de șpan cu melc și palpator de scule Renishaw OTS. Considerați oportunitatea de a achiziționa acest centru de prelucrare vertical HAAS VF-4. Contactați-ne pentru mai multe informații despre această mașină. Tipuri de aplicații: Frezare

Stare: gata de utilizare (folosit), An de fabricație: 2007, Unitate de control Marcă: SIEMENS Model: Sinumerik Deplasare Deplasare axă X: 1400 mm Deplasare axă Z: 600 mm Deplasare axă Y: 700 mm Această mașină WAGNER VMC 1400 cu 4 axe a fost fabricată în 2007. Dispune de o putere a arborelui principal de 28 kW, cuplu maxim al arborelui principal de 230 Nm și turație de până la 4000 rpm. Include un al patrulea ax pentru prelucrarea pieselor până la 1100 mm. Ideală pentru operațiuni complexe de prelucrare. Contactați-ne pentru mai multe informații despre această mașină. Gtsdpfx Ajx D Elwehyjw Tipuri de aplicații Frezare

Stare: foarte bun (second hand), An de fabricație: 1986, RAFAMET tip KCF 400 Mai multe informații la cerere Gedpfx Aeytq T Hshyetw
