Ariston Strung cumpărați folosit (3.877)

Stare: gata de utilizare (folosit), Funcționalitate: complet funcțional, lungime de strunjire: 630 mm, înălțime centru: 270 mm, înălțimea centrului în arborele cotit: 138 mm, pas de filet metric (max.): 10 mm, pas de filet metric (min.): 25 mm, diametru de strunjire deasupra saniei transversale: 250 mm, diametru de strunjire peste patul saniei: 250 mm, diametru de strunjire: 250 mm, lățime totală: 2.975 mm, lățime la centru: 900 mm, diametrul discului: 250 mm, înălțime totală: 1.100 mm, lungime totală: 2.750 mm, diametru de strângere: 250 mm, prindere conică: 5 mm, viteză de rotație (min.): 28 rot/min, puterea motorului arborelui principal: 4.000 W, diametru de oscilație peste sania transversală: 250 mm, diametru de oscilație deasupra tălpii transversale: 250 mm, interval de pivotare: 360 °, diametru quill: 80 mm, trăsătură de pană: 16 mm, cursa axului: 32 mm, viteză de rotație (max.): 450 rot/min, Dotări: documentație / manual, viteză de rotație variabilă continuu, Strung de profilare cu eliberare NILES DH 250/4 (Strung specializat de eliberare și profilare) NILES DH 250/4 este un strung de înaltă precizie proiectat pentru executarea eficientă a operațiunilor de profilare, eliberare și finisare pe piese cilindrice cu diametrul de până la 250 mm. Fabricat de NILES, un producător german de mașini-unelte cu reputație, acest utilaj combină o construcție mecanică robustă cu o comandă lină a mișcării, pentru a asigura rezultate constante în medii exigente de atelier. Acest strung este ideal pentru ateliere de scule, secții de reparații și unități de producție unde este necesară eliberarea profilului sculelor sau a componentelor. Dispozitivul integrat de eliberare, construit solid, asigură o acuratețe ridicată și repetabilitate la operațiunile de profilare, inclusiv pentru cele ce nu pot fi realizate ușor pe strunguri convenționale. Platanul cu diametrul de 250 mm permite strunjirea unei game largi de piese cu diametrul de până la 250 mm, la o lungime de strunjire de 630 mm. Piesele sunt fixate sigur pe sistemul centrat bine proiectat, având o înălțime pe centru de 270 mm deasupra şinelor şi o distanță între vârfuri de 900 mm. Platanul detașabil și montajul con Morse nr. 5 oferă flexibilitate pentru diferite opțiuni de prindere și scule. Axul principal oferă o gamă reglabilă continuu de turații, între 28 și 450 rpm, acționat de un motor de 4 kW, permițând selecția precisă a vitezei atât pentru tăieri brute, cât și pentru operații de finisare cu eliberare. Coadă mobilă (călăuze) integrată are diametrul de 80 mm și o cursă maximă de 16 mm, asigurând mișcări controlate de profilare. Gjdpfx Abox Sq H Souobw NILES DH 250/4 vine însoțit de documentația din fabrică, facilitând integrarea ușoară în fluxurile industriale și întreținerea regulată. Construcția generală — aproximativ 2750 mm lungime, 2975 mm lățime și 1100 mm înălțime — reflectă designul său stabil și durabil. Caracteristici principale: * Strung pentru eliberare și profilare specializată * Diametru maxim de strunjire: 250 mm * Lungime de strunjire până la 630 mm * Diametru platan: 250 mm * Înălțime pe centru: 270 mm * Turație continuu variabilă: 28 – 450 rpm * Puterea motorului de antrenare ax principal: 4 kW * Diametru călăuză: 80 mm, cursă 16 mm * Con Morse nr. 5 pentru montajul axului * Construcție grea industrială, cu documentație de fabrică inclusă Aplicații tipice: * Operații de eliberare și profilare a componentelor cilindrice * Strunjire de scule cu eliberare și profilare de finisare * Prelucrări specializate în serii mici * Lucrări de întreținere și ateliere de sculărie

Stare: bun (utilizat), An de fabricație: 2008, Funcționalitate: complet funcțional, număr mașină/vehicul: 101868, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Lenght=2680mm(3820 with chip extractor),Wide=2040 mm,Height=2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales Gjdpfxexwk U De Abuebw # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : WORKING

Stare: foarte bun (second hand), De vânzare: Mașină industrială de frezat pentru prelucrarea buștenilor rotunzi, model MC9050B, fabricată în 2018, concepută pentru producerea de stâlpi din lemn rotunzi și componente cilindrice din lemn, cum ar fi mânere de unelte, cozi de mătură, piese de mobilier și produse similare. Specificații: • Model: MC9050B Gjdpfx Abezmt U Ejusbw • Anul fabricației: 2018 Crsbezmt U Eemrvd Ikeg • Alimentare: 380V (trifazic) • Diametrul de lucru: 15–50 mm • Lungimea minimă a piesei de prelucrat: 600 mm • Motor principal: 3 kW • Greutate aproximativă: 350 kg Stare: • Stare de funcționare excelentă. • Mașină completă, gata de utilizare imediată. • Se pot efectua inspecții și teste.

Stare: folosit, An de fabricație: 2012, Funcționalitate: complet funcțional, număr mașină/vehicul: LZ1R0503, Technical characteristics: Work Area # Maximum turning diameter: 89 mm # Maximum workpiece length: 80 mm # Chuck size: 152 mm hydraulic drive # Maximum workpiece weight : 0.7Kg*2 # X - axis travel distance: 245 mm / Rapid speed in X: 20 m/min # Z - axis travel distance: 240 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : ASA 6 # Maximum speed: 60-6000 rpm # Power with 100% ED : 7.5 / 5.5 kW Tool Holder with Motorized Tools # Tool Interface: 20 mm square / 25 hole diameter # Number of position : 12 lower -station disc turret, 6 driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW # turret indexation time : 0.2 sec Electrical Equipment # Operating voltage: 200Vx3 # Connection power: 21 kVA Dimensions # Machine Dimensions (L×W×H): 2,100 × 1,555 × 1680 mm ;Weight : 4000 Kg Main Features and Capabilities: Gbsdpfexxr Dvex Abusw # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: Fanuc Series 21i TB # Chip extraction conveyor Machine status : WORKING

Stare: folosit, An de fabricație: 2007, Funcționalitate: funcționalitate restrânsă, număr mașină/vehicul: P-30008793, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 Godpfx Abexxr Rpouobw # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length=2680 mm(3820 with chip extractor),Wide=2040 mm,Height=2400 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available & Book available Machine status : WORKING # Safety switch operator panel broken

Stare: folosit, An de fabricație: 2007, Funcționalitate: complet funcțional, număr mașină/vehicul: 100864, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Gjdpfxsxxttfe Abujbw Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length=2680 mm(3820 with chip extractor),Wide=2040 mm,Height=2400 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Haidenhein liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available & Book available Machine status : WORKING

Stare: folosit, An de fabricație: 1997, Funcționalitate: complet funcțional, număr mașină/vehicul: W301002, Technical characteristics: Work Area # Maximum turning diameter: 270 mm # Maximum machining diameter: 215 mm # Maximum workpiece length: 265 mm # Distance between spindle noses: 1080 mm # X1/X2 - axis travel distance: 195 mm / Rapid speed in X: 12 m/min # Z1/Z2 -axis travel distance: 265/780 mm / Rapid speed in Z: 24 m/min # B -axis travel distance(Right Spindle Travel) : 850 mm / Rapid speed in Z: 24 m/min Spindles # Spindle according to DIN 55026: Size A2-6 # Maximum speed: Left & Right from 50 to 5000 rpm # Power with 100% ED : Left 11 kW / Right11 kW # Main spindle feature : option double command clamping cycle for clamping chuck in 2 steps # Bar Capacity: left spindle 51 mm / right spindle 51 mm 2 Turrets # Tool Interface: BMT55 # Number of position : 12-station disc turret Electrical Equipment # Operating voltage: 200/220VAC+10%/15%,1 fase, 50/60 Hz # Connection power: 54 kVA (connection 61 VA) Dimensions # Machine Dimensions (L×W×H): 3645 × 1875 × 1970 mm # Weight : 10800 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation and easy loading/unloading. # CNC Control: Fanuc 6i-TT # Chip extraction conveyor # Automation interface available for Gantry loader # Main Spindle with Autoblock Chuck installed 265 TXS Gedpsxw Uh Iofx Abusbw # Turret equipped with 2 external tool holders each # Documentation : Electronic not available / Book available Machine status : WORKING

Stare: neverificat (folosit), An de fabricație: 2011, Funcționalitate: neverificat, număr mașină/vehicul: 01620006501, lungime de strunjire: 650 mm, diametru de strunjire: 350 mm, turația arborelui principal (max.): 4.500 rot/min, distanța de deplasare pe axa X: 255 mm, cursa axei Z: 800 mm, avans rapid axa X: 30 m/min, avans rapid pe axa Z: 30 m/min, înălțime totală: 1.800 mm, lungime totală: 4.500 mm, lățime totală: 2.200 mm, greutate totală: 3.000 kg, trecere bară: 65 mm, producător de controlere: HEIDENHAIN, model de controler: CNC PILOT 620, tensiune de intrare: 400 V, frecvență de intrare: 50 Hz, curent de intrare: 35 A, putere nominală (aparentă): 21 kVA, ore de funcționare ale axului: 10.771 h, DMG NEF 400, strung CNC - Diametrul maxim de prelucrare peste pat: 385 mm - Diametrul maxim de prelucrare peste sanie: 350 mm - Distanța dintre centre: 805 mm - Cursa axei Z, axa port-piese: 680 mm - Înălțimea flanșei axului deasupra solului: 1000 - 1010 mm - Diametrul flanșei axului: 170 H5 mm - Diametrul chuck-ului: 200/250 mm - Diametrul găurii interne a axului: 87 mm - Diametrul tubului de ghidare: 67,5 mm - Diametrul la rulmentul din față: 100 mm - Include axa C1, turație: 200 RPM - Forța de avans în axa X/Z, S1: 4,5 / 6,2 kN - Forța de avans în axa X/Z, S6: 6/8,5 kN - Șurub cu bilă pentru axa X/Z: 32 x 10 mm Gbjdpfx Ae Afun Ijbujw - Diametrul suportului pentru scule: VDI 30 - Număr de scule: 12 bucăți, dintre care 6 sunt acționate - Tija sculei: 20 x 20 mm - Cursa axei port-piese: 680 mm - Forța maximă de avans: 680 daN - Con Morse: MK 4 Mașina este echipată cu un port-piese, un revolver SAUTER și un chuck cu trei fălci de la producătorul SCHUNK, lățimea fălcii: 210 mm, cu strângere hidraulică, inclusiv diverse suporturi pentru scule VDI 30, unele acționate și altele normale, unele echipate cu accesorii pentru strung, precum și un transportor de așchii și documentație. FCA D-94227 Zwiesel - încărcat pe un camion.

Stare: necesită reparații (utilizat), An de fabricație: 2017, Funcționalitate: nefuncțional, număr mașină/vehicul: 108113, Technical characteristics: Work Area Gedpfx Aboxxip Aeujbw # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor & coolant filtration unit Knoll with ''paper filter'' with 40 Bar pumps ( capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # LT motor Broken,repairable # Operator panel, safety switch & 2 buttons broken need to be replaced

Stare: folosit, An de fabricație: 2009, Funcționalitate: complet funcțional, număr mașină/vehicul: 3XR2L03, Technical characteristics: Work Area Gedpjxxtu Asfx Abujbw # Maximum turning diameter: 89 mm # Maximum workpiece length: 80 mm # Chuck size: 152 mm hydraulic drive # Maximum workpiece weight : 0.7Kg*2 # X - axis travel distance: 245 mm / Rapid speed in X: 20 m/min # Z - axis travel distance: 240 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : ASA 6 # Maximum speed: 60-6000 rpm # Power with 100% ED : 7.5 / 5.5 kW Tool Holder with Motorized Tools # Tool Interface: 20 mm square / 25 hole diameter # Number of position : 12 lower -station disc turret, 6 driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW # turret indexation time : 0.2 sec Electrical Equipment # Operating voltage: 200Vx3 # Connection power: 21 kVA Dimensions # Machine Dimensions (L×W×H): 2,100 × 1,555 × 1680 mm ;Weight : 4000 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: Fanuc Series 21i TB # Chip extraction conveyor Machine status : WORKING

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107964, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Cooling Pump x2 units # Life Tool Motor # Oiling Pump # Operator panel - touch screen need to be changed # Hydraulic block valves x 3 units # Hydraulic cylinder loading door # Rotary Joint # Oiling Pressure switch # Safety door Euchner Gbsdoxw Srkspfx Abujw

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107965, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor & coolant filtration unit Knoll with ''paper filter'' with 40 Bar pumps ( capable to filter 2 Machines) # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Life tool Motor # Loading door Safety Euchner # Turret Motor # Driver turret Motor # Oiling pump # Hydraulic block electrovalvula x4 units # Oiling pressure Gbsdexw Svispfx Abuow # Rotary joint # Loading door hydraulic cylinder # Spindle clamp/unclamp sensor

Stare: neverificat (folosit), An de fabricație: 2004, Funcționalitate: neverificat, număr mașină/vehicul: 01360000541, lungime de strunjire: 600 mm, diametru de strunjire: 320 mm, alezor axului principal: 87 mm, turația arborelui principal (max.): 5.000 rot/min, distanța de deplasare pe axa X: 230 mm, cursa axei Z: 500 mm, avans rapid axa X: 24 m/min, avans rapid pe axa Z: 30 m/min, înălțime totală: 2.300 mm, lungime totală: 4.000 mm, lățime totală: 2.000 mm, diametru quill: 120 mm, trăsătură de pană: 150 mm, greutate totală: 5.000 kg, producător de controlere: HEIDENHAIN, model de controler: CNC PILOT 4290, tensiune de intrare: 400 V, frecvență de intrare: 50 Hz, curent de intrare: 80 A, putere nominală (aparentă): 44 kVA, Cursa pinolei păpușii mobile: 580 mm, ore de funcționare ale axului: 22.794 h, GILDEMEISTER CTX 400 C – Mașină de strung CNC - Diametrul maxim de prelucrare: 505 mm - Diametrul maxim de prelucrare peste ghidajul X: 365 mm - Diametrul maxim al barei: 65/75 mm - Diametrul axului în rulmentul frontal: 130 mm - Diametrul chuck-ului: 200/250 mm - Puterea motorului: 21 kW - Inclusiv axa C – turație: 200 rpm - Precizia poziționării: 0,04° - Șurub cu bile X/Z: 32 x 10 mm - Forța de avans X/Z: 4/6 kN Gbsdpfxo Afutde Abujw - Inclusiv schimbător automat de scule cu 12 poziții - Numărul de posturi de scule acționate: toate cele 12 - Diametrul tijei: VDI 30 - Disc de scule, prindere axială a sculei: diametrul cercului de divizare: 340 mm - Inclusiv contra-centru, cursa contra-centrului: 580 mm - Con de centrare: MK 4 - Inclusiv posturi cu prindere VDI 30 acționată – compatibilă cu mașina - Cu sistem de evacuare a așchiilor și documentație Mașina este echipată cu un contra-centru, un chuck cu 3 bacuri, diametru: 200 mm și un revolver de scule cu 12 poziții, VDI 30. FCA D-94227 Zwiesel – încărcată pe camion

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: 106374, Technical characteristics: Work Area # Chuck diameter: 160 mm # Weight max.chuck + work part : 45 Kg # Workpiece dia. / height max.: 100/400 mm # Distance spindle nose vs. origin tails stock : 795.5 mm # X1/X2 stroke(working stroke): 340 mm / Rapid speed in X: 30 m/min # Z1/Z2 stroke: 625 mm / Rapid speed in Z: 30 m/min / feed force 18.7 kN # Loading time : 5÷6 sec # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size KK5 # Maximum speed: 8500 rpm # Power with 100 / 40% duty cycle: 34 / 26.5 kW # Torque with 100 / 40% duty cycle: 75 / 48 Nm Tailstock # Interface: MK3 # Clamping force: 120 N/ bar # Clamping stroke: 5 mm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 2 x 12 (1 gripper each turret) # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,120 A # Connection power: 45 kVA Dimensions # Total dimensions: Length=5300 with chip extractor,Wide=1760 mm,Height=3650 mm # Weight : 7500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and automatic loading/unloading. # Control: GE Fanuc FS 32i # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Haidenhein liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Emag O-Type Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor Coolant unit Switchable double cartridge filter High pressure pump 15 bar # Fully enclosed work area Light in working area # Documentation : Electronic available & Book available Machine status : NOT WORKING # Driver axa X Gjdpfxoxxtkwo Abuobw # Electrical switches 5 units (Siemens) # Hydraulic Pump # Operator panel - on stock need to be installed # Valve chiller # Pressure switch for oiling unit # Pump for emulsion tank # Emulsion circuit switches 4 units (electrovalve) # Pressure switch for hydraulic circuit # Complete hydraulic block

Stare: necesită reparații (utilizat), An de fabricație: 2015, Funcționalitate: nefuncțional, număr mașină/vehicul: MW137, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Gsdpfx Abjxxh Udouobw Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, fusible 151A # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # ADDITIONAL EMULSION TANK WITH 10BAR PRESSURE FOR CUTTING TOOL COOLING # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL - # Barr feeder : FMB model : Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 ×800× 1200 mm; Weight: 1500 Kg Machine status : NOT WORKING # Encoder X axis - broken

Stare: necesită reparații (utilizat), An de fabricație: 2014, Funcționalitate: nefuncțional, număr mașină/vehicul: 67137, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 250 mm # Maximum turning diameter: 250 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 200 mm # X-axis travel distance: 886 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 250 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: -85/+100 mm / Rapid speed in Z: 30 m/min Gbjdpfx Aboxxi Urouew # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle (Weiss) according to DIN 55026: Size A6 # Maximum speed: 5500 rpm # Power with 100% OT: 38 kW # Torque with 100% OT : 300 Nm Secondary Spindle HSK63 # Spindle Head Size/type :HSK-A63 # Nominal speed: 2700 rpm / Nominal Power 12 kw /nominal torque 42.4 Nm # Maximum speed: 15000 rpm # Power with 100% OT: 38 kW # Torque with 100% OT : 300 Nm Tool Holder with Motorized Tools # turret VDI40, Siemens-drive 0.5.440.220 Fabr. Sauter # Number of position : 12 # Life tool nominal speed : 3000 U/min , nominal torque 33.1 Nm # Life tool maxim speed : 10000 U/min , nominal torque 56.2 Nm # Life tool nominal power 100% OT : 10.4 Kw Electrical Equipment # Operating voltage: 400 V, fusible 100A GL # Connection power: 45 kW Dimensions # Total dimensions: Length=4021 mm,Wide=4709 mm,Height=3527 mm # Weight : 8000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D SL # High Precision: Positioning accuracy in X,Z,Y Heidenhain liniar scales # Main Spindle Weiss: High power and wide speed range. # Secondary Spindle Weiss: High power and wide speed range.( easy access for drilling/milling operations ) # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Control in process probe : Marposs T25 # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor : Knoll # Coolant ''paper'' filtering unit & cooling : Knoll KF150/500 # Electrostatic mist filter : IFS type IFM1000 Machine status : NOT WORKING # Sauter turret replaced with new one, assembly process not finished - assembly of turret motor spindle to be finished # safety switch of Operator panel need to be replaced

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: 107786, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 160 mm # Maximum turning diameter: 160 mm # Maximum machining diameter: 100 mm # Maximum workpiece length: 150 mm # X-axis travel distance: 700 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 375 mm / Rapid speed in Z: 30 m/min Gbodpfx Asxw Slkebuew # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size A5 # Maximum speed: 6000 rpm # Power with 100 / 40% duty cycle: 18.1 / 13.9 kW # Torque with 100 / 40% duty cycle: 77 / 59 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V ,80 A # Connection power: 27 kVA Dimensions # Total dimensions: Length=4350 with chip extractor,Wide=1600 mm,Height=2500 mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Tool life time monitoring with sister tool management # Chip conveyor # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Operator panel - touch screen need to be changed # Hydraulic cylinder loading door broken # Emulsion Pump # Hydraulic pump # Spindle clamp unclamp sensor # Hydraulic pressure accumulator # Turret motor

Stare: necesită reparații (utilizat), An de fabricație: 2008, Funcționalitate: nefuncțional, număr mașină/vehicul: M234205, Technical characteristics: Work Area # Maximum turning diameter: 250 mm # Maximum machining diameter: 250 mm # Maximum workpiece length: 555 mm # X1/X2 - axis travel distance: 195 mm / Rapid speed in X: 30 m/min # Z1/Z2 -axis travel distance: 600mm / Rapid speed in Z: 30 m/min # Y-Axis (Upper Turret)travel distance: +/-41mm / Rapid speed in Z: 30 m/min # B -axis travel distance(Right Spindle Travel) : 620 mm / Rapid speed in Z: 30 m/min Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: Left 4500 rpm / Right 5000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Bar Capacity: left spindle - 65 mm / right spindle - 51 mm Tool Holder with Motorized Tools # Tool Interface: BMT55 # Number of position : 12-station disc turret, all driven positions Godpfx Asxxvw Hobuobw # Maximum speed: 6000 rpm, Milling motor power : 3.7kW Electrical Equipment # Operating voltage: 200Vx3, fusible 217A GL # Connection power: 75 KVA Dimensions # Machine Dimensions (L×W×H): 4,059 × 2,314 × 2,225 mm # Weight : 6000 Kg Main Features and Capabilities: # horizontal Design: Optimal chip evacuation and easy loading/unloading. # CNC Control: Fanuc 18i-T # Chip extraction conveyor # Barr feeder interface # Documentation : Electronic not available / Book available Machine status : NOT WORKING # B axis not functional # Lower turret not functional

Stare: necesită reparații (utilizat), An de fabricație: 2016, Funcționalitate: nefuncțional, număr mașină/vehicul: MW144, Technical characteristics: Work Area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X - axis travel distance: 250 mm / Rapid speed in X: 24 m/min # Z - axis travel distance: 460 mm / Rapid speed in Z: 24 m/min # W -axis travel distance: 520 mm / Rapid speed in Z: 24 m/min Main Spindle # Spindle size : A2-8 # Maximum speed: Left 3000 rpm # Power with 100% ED : Left -15 kW / Right 7.5 kW # Max diameter on bench: 520 mm # C axis indexing precision : 0.001 [°] # Bar Capacity: left spindle - 80 mm / right spindle - 53 mm Counter- Spindle: # Spindle speeds : 6000 [rpm] # Max. bar diameter : 53 [mm] # C axis indexing precision : 0.001 [°] # Travel : 520 [mm] Tool Holder with Motorized Tools # Tool Interface: Okuma interface # Number of position : 12 lower -station disc turret, all driven positions # Maximum speed: 4500 rpm, Milling motor power : 4.5 kW Electrical Equipment # Operating voltage: 400Vx3, # Connection power: 22.5 kVA Dimensions # Machine Dimensions (L×W×H): 3200 ×2200× 1900 mm ;Weight : 5500 Kg Godpfx Ajxxidaebujbw Main Features and Capabilities: # horizontal Design: Optimal chip evacuation, Parts catcher + Custom made Parts conveying strip # CNC Control: OSP-P300L-R # Chip extraction conveyor # FIRE PROTECTION SYSTEM # TOOL MEASURING SYSTEM (Q SETTER) # Broken tool detection system : Load force auto learning analyzer controlled by OSP-P300L-R # Part detection Counter spindle : Low pressure compressed air gauges. # SPINDLE COOLING SYSTEM, # Documentation : Electronic available / Book available OPTIONAL Barr feeder : TOP Automazzione model : FU 352 # Bar feeder (L×W×H): 3500 ×800× 1200 mm ;Weight : 1500 Kg Machine status : NOT WORKING # Turret -disassembled to be repaired # Ball screw X axis - to be replaced # Heat exchanger oiling unit - to be replaced # Hydraulic unit - to be replaced # Sub spindle - to be repaired # Position encoder Spindle - to be replaced # Chip conveyor - to be repaired # Kit of guides and accessories for bars clamping # Kit of bearings for pusher head

Stare: necesită reparații (utilizat), An de fabricație: 2011, Funcționalitate: nefuncțional, număr mașină/vehicul: 102920, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 250 mm # Maximum turning diameter: 270 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 175 mm # X-axis travel distance: 660 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 300 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 V # Connection power: 36 kW / 80A Dimensions # Total dimensions: Length=3120mm(4185 with chip extractor),Wide=2266 mm,Height=3200 mm # Weight : 7500 Kg Gbodpexxiwyofx Abusw Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens 840D # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Part detection sensor with compressed air gage throw spindle : SMW Autoblock Linear Position Sensor LPS-X # Control in process: Marposs T25 # Chip extraction conveyor # Coolant refrigeration system : Texa Model TCW55PMSBXMF000 max 30 bar input # Coolant filtration with "paper'' filter : Micron filter Model EVO500Pro+KMT150 550 liters 80l/min # Documentation : Electronic & Book available Machine status : NOT WORKING # Motor from Lifetool # Slideways & patines X & Z axis # Hydraulic pressure compensation block

Stare: necesită reparații (utilizat), An de fabricație: 2006, Funcționalitate: nefuncțional, număr mașină/vehicul: 00592, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 200 mm # Maximum machining diameter: 130 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 400 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 7500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 3x 400 - 480 V , 50A # Connection power: 31 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 5500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available / Book available Gbedsxwlbxepfx Abujw Machine status : NOT WORKING # Motor from Life tool broken # Reductor from life tool broken

Stare: necesită reparații (utilizat), An de fabricație: 2017, Funcționalitate: nefuncțional, număr mașină/vehicul: 109238, Technical characteristics: Work Area # Chuck diameter: 260 mm # Weight max. : 150 Kg # Swing diameter: 280 mm # Workpiece dia. / height max.: 200/200 mm # X stroke(working stroke): 760 mm / Rapid speed in X: 60 m/min / feed force 6.9 kN # Z stroke: 415 mm / Rapid speed in Z: 30 m/min / feed force 18.7 kN # Loading time : 5÷6 sec # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 25 / 18 kW # Torque with 100 / 40% duty cycle: 280 / 200 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - BMT65 # Number of position : 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 27 Nm,100% duty cycle: 14 Nm Gedjxxkgpopfx Abujbw Electrical Equipment # Operating voltage: 400 - 480 V ,100 A # Connection power: 36 kVA Dimensions # Total dimensions: Length=5300 with chip extractor,Wide=2300 mm,Height=3650 mm # Weight : 9000 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE Fanuc FS 32i B. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Control in process: Measuring probe Marposs T25 # Automated Loading/Unloading: Emag O-Type Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip conveyor Coolant unit Switchable double cartridge filter High pressure pump 15 bar # Tool life time monitoring with sister tool management # Fully enclosed work area Light in working area # Documentation : Electronic available & Book not complete Machine status : NOT WORKING # Converter hydraulic electrical motor # Life tool motor

Stare: foarte bun (second hand), An de fabricație: 2007, Funcționalitate: complet funcțional, diametru de strunjire: 270 mm, număr de cuțite pentru rindeluire: 4, Dincmak EKS T4 Z – 2007 Tipul mașinii: Strung pentru copierea lemnului, cu unitate de șlefuire Capacitatea lungimii de lucru: 1200 mm Puterea motorului pentru lamă: 3 kW x 2 Puterea motorului pentru suport: 1,5 kW Viteza de rotație a frezei: 5000 rpm Viteza de deplasare a suportului: 0 – 15 m/min Gjdpfx As Ah R Tiebuobw Greutate: 2000 kg Numărul de axe: 1 pentru model și 4 pentru piesa de prelucrat Capacitatea de producție: Patru piese de prelucrat per operație Sistem de copiere: Urmărire pneumatică a unui șablon tridimensional Centrarea piesei de prelucrat: Pneumatică Avansul suportului: Automat, cu sistem de avans cu șurub cu bilă Ghidajele suportului: Glisiere cu rulmenți liniari Controlul avansului: Două zone de viteză reglabile Construcție: Corp din oțel închis Siguranță: Măsuri de siguranță electronice Aplicații: Componente din lemn cu forme complexe, inclusiv picioare de mobilier și mânere pentru scule.

Stare: necesită reparații (utilizat), An de fabricație: 2012, Funcționalitate: nefuncțional, număr mașină/vehicul: 103563, Technical characteristics: Work Area: # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Y-axis travel distance: 40 mm / Rapid speed in Y: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle: # Spindle according to DIN 55026: Size 6 # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions # Total dimensions: Length =2680mm(3820 with chip extractor),Wide=2040 mm, Height =2400mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: Siemens Sinumerik 840D-sl. # High Precision: Positioning accuracy in X,Z and Y axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor Machine status : NOT WORKING # Motor from Life tool - dismantled from machine Gbodpfxsxvyk Ee Abuew # Spindle broken - dismantle from machine # Turret dismantled ( leakage if cooling coolant throw refrigeration circuit of turret )

Stare: necesită reparații (utilizat), An de fabricație: 2007, Funcționalitate: nefuncțional, număr mașină/vehicul: P-30010522, Technical characteristics: Work Area # Maximum diameter of the clamping plate: 260 mm # Maximum turning diameter: 260 mm # Maximum machining diameter: 220 mm # Maximum workpiece length: 110 mm # X-axis travel distance: 570 mm / Rapid speed in X: 60 m/min # Z-axis travel distance: 200 mm / Rapid speed in Z: 30 m/min # Standard closed automation (number of loading nests with a workpiece diameter ,14/(80...200),18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 !!! Brand New replaced 2024 !!! # Maximum speed: 4500 rpm # Power with 100 / 40% duty cycle: 18 / 27 kW # Torque with 100 / 40% duty cycle: 202 / 303 Nm Tool Holder with Motorized Tools # Cylindrical shank supports according to DIN 69880: 12 - VDI40 # Number of position : 12 # Maximum tool length including holder: 190 mm # Maximum speed: 6000 rpm # Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm,100% duty cycle: 14 Nm Electrical Equipment # Operating voltage: 400 - 480 V # Connection power: 42 kW Dimensions Gjdpfx Abexxkh Tjujbw # Total dimensions: Length=2680 mm (3820 with chip extractor),Wide=2040 mm,Height=2400 mm # Weight : 6500 Kg Main Features and Capabilities: # Vertical Design: Optimal chip evacuation and easy loading/unloading. # Control: GE FanucSeries 18i TB. # High Precision: Positioning accuracy in X,Z axes is ±0.001 mm Heidenhain liniar scales # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. # Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. # Chip extraction conveyor # Documentation : Electronic not available & Book partially available Machine status : NOT WORKING # Hydraulic electro valve x4 units # Emulsion pump broken
